- Basic Specifications - Capacity
- Guest networks: 6
- Basic Specifications - Cellular Protocol
- HSPA+, LTE, FDD LTE, TDD LTE
- Basic Specifications - Compliant Standards
- IEEE 802.3, IEEE 802.3u, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.1x, IEEE 802.11i, IEEE 802.11e, IEEE 802.11n, UPnP, IEEE 802.11ac
- Basic Specifications - Data Link Protocol
- Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac
- Basic Specifications - Device Type
- Wireless router - wireless cellular modem - 4-port switch (integrated)
- Basic Specifications - Dimensions (WxDxH)
- 24.2 cm x 10 cm x 32.5 cm
- Basic Specifications - EAN
- 4718017730327
- Basic Specifications - Enclosure Type
- Desktop
- Basic Specifications - Features
- SPI, print server, IPv6 support, parental control, Access Point operational mode, MIMO technology, event log, QoS, dual WAN connection, WPS, IPSec passthrough, DNS proxy, port forwarding, ASUS AiDisk, reset button, IPv4 support, port triggering, Multicast Proxy support, VPN Server, ASUS AiCloud, Multicast Rate Setting support, PPTP passthrough, L2TP passthrough, MU-MIMO technology, Roaming Assist technology, beamforming technology, Adaptive QoS, Smart QoS, VPN client, ASUS Router App, NTP client, Smart Connect, RangeBoost, DoS protection, DMZ support, Traffic Analyser, Bandwidth Limiter, ASUS AiProtection Pro, L2TP client, PPTP client, PPTP server, OpenVPN client, OpenVPN server, IPTV support, WAN bridge support, NAT passthrough
- Basic Specifications - Frequency Band
- 2.4 GHz / 5 GHz
- Basic Specifications - Manufacturer's Part Number
- 4G-AC86U
- Basic Specifications - Mobile Communication Protocol
- HSPA+, LTE, FDD LTE, TDD LTE
- Basic Specifications - Model
- ASUS 4G-AC86U
- Basic Specifications - Network / Transport Protocol
- PPTP, L2TP, NTP, IPSec, DHCP, DDNS
- Basic Specifications - Product Description
- ASUS 4G-AC86U - wireless router - WWAN - Wi-Fi 5 - desktop
- Basic Specifications - Routing Protocol
- IGMPv2, IGMP, IGMPv3
- Basic Specifications - Service Provider
- Service not included
- Basic Specifications - WAN Ports Qty
- 1
- Basic Specifications - Weight
- 787 g
- Communications - Max Transfer Rate
- 600 Mbps
- Communications - Mobile Communication Protocol
- HSPA+, LTE, FDD LTE, TDD LTE
- Communications - Type
- Wireless cellular modem
- Dimensions & Weight - Depth
- 10 cm
- Dimensions & Weight - Height
- 32.5 cm
- Dimensions & Weight - Weight
- 787 g
- Dimensions & Weight - Width
- 24.2 cm
- Environmental Parameters - Humidity Range Operating
- 10 - 95% (non-condensing)
- Environmental Parameters - Max Operating Temperature
- 40 °C
- Environmental Parameters - Min Operating Temperature
- 0 °C
- Expansion / Connectivity - Expansion Slots
- 1 (total) / 1 (free) x Nano-SIM
- Expansion / Connectivity - Interfaces
- WAN: 1 x 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ LAN: 4 x 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ USB 2.0: 1 x 4 pin USB Type A
- General - Capacity
- Guest networks: 6
- General - Compliant Standards
- IEEE 802.3, IEEE 802.3u, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.1x, IEEE 802.11i, IEEE 802.11e, IEEE 802.11n, UPnP, IEEE 802.11ac
- General - Connectivity Technology
- Wireless, wired
- General - Data Link Protocol
- Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac
- General - Device Type
- Wireless router - 4-port switch (integrated)
- General - Enclosure Type
- Desktop
- General - Encryption Algorithm
- 128-bit WEP, WPA-PSK, WPA2-PSK, WPA-Enterprise, WPA2-Enterprise
- General - Features
- SPI, print server, IPv6 support, parental control, Access Point operational mode, MIMO technology, event log, QoS, dual WAN connection, WPS, IPSec passthrough, DNS proxy, port forwarding, ASUS AiDisk, reset button, IPv4 support, port triggering, Multicast Proxy support, VPN Server, ASUS AiCloud, Multicast Rate Setting support, PPTP passthrough, L2TP passthrough, MU-MIMO technology, Roaming Assist technology, beamforming technology, Adaptive QoS, Smart QoS, VPN client, ASUS Router App, NTP client, Smart Connect, RangeBoost, DoS protection, DMZ support, Traffic Analyser, Bandwidth Limiter, ASUS AiProtection Pro, L2TP client, PPTP client, PPTP server, OpenVPN client, OpenVPN server, IPTV support, WAN bridge support, NAT passthrough
- General - Flash Memory
- 128 MB
- General - Frequency Band
- 2.4 GHz / 5 GHz
- General - Network / Transport Protocol
- PPTP, L2TP, NTP, IPSec, DHCP, DDNS
- General - Processor
- 1 x 1.35 GHz
- General - RAM
- 512 MB
- General - Routing Protocol
- IGMPv2, IGMP, IGMPv3
- General - Service Provider
- Service not included
- General - Status Indicators
- Power, WAN, LAN, USB, Wi-Fi
- General - Wi-Fi Rating
- AC2600
- Miscellaneous - Cables Included
- 1 x network cable
- Power - Power Device
- External power adapter
