- 80 PLUS Certification :
- Platinum
- ATX Standard :
- ATX 3.1
- Brand :
- Gigabyte
- Cable Type :
- All-Black Embossed Cables
- Colour :
- Black
- Combined +12V Output :
- 849.6W
- Cooling TyOver Voltage Protection : Yespe :
- Active Cooling
- CPU Connectors :
- 2 x 4+4-Pin EPS
- Dimensions :
- 150 x 140 x 86mm
- Fan Size :
- Fan Size : 120mm
- Fan Stop Function :
- Supported Under Low Load
- Fan Type :
- Fluid Dynamic Bearing (FDB)
- Hold-Up Time :
- Greater Than 16ms
- Input Current :
- 12–6A
- Input Frequency :
- 50–60Hz
- Input Voltage :
- 100–240V AC
- Japanese Capacitors :
- 100%
- Maximum +12V Current :
- 70.8A
- Motherboard Connector :
- 1 x 20+4-Pin ATX
- MTBF :
- Greater Than 100,000 Hours
- Native 16-Pin Connector :
- 1 x PCIe 16-Pin
- No Load Operation Protection :
- Yes
- Over Current Protection :
- Yes
- Over Power Protection :
- Yes
- Over Temperature Protection :
- Yes
- PCIe 16-Pin Power Output :
- Up to 600W
- PCIe Connectors :
- 6 x 6+2-Pin
- PCIe Standard :
- PCIe 5.1
- Peripheral Connectors :
- 4 x 4-Pin Molex
- PFC Rating :
- Greater Than 0.9 Typical
- Power Excursion Capability :
- Up to 200% Total Power and 300% GPU Power
- Power Factor Correction :
- Active PFC
- Power Good Signal :
- 100–150ms
- Power Rail Design :
- Single +12V Rail
- Power Supply Depth :
- 140mm
- Power Supply Form Factor :
- ATX
- Power Switch :
- Yes
- Product Family :
- AORUS
- Product Type :
- ATX Power Supply Unit
- Rated Power Output :
- 850W
- SATA Connectors :
- 8
- Short Circuit Protection :
- Yes
- Smart Fan Control :
- Yes
- Surge and Inrush Protection :
- Yes
- Typical Efficiency :
- Up to 92% at 50% Load
- Under Voltage Protection :
- Yes
