- Aerial - Antenna
- Internal
- Basic Specifications - Capacity
- Spatial streams: 4 ¦ Connected devices: 200+
- Basic Specifications - Data Link Protocol
- IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6), IEEE 802.11be (Wi-Fi 7)
- Basic Specifications - Device Type
- Radio access point
- Basic Specifications - Dimensions (WxDxH)
- 17.15 cm x 3.3 cm x 17.15 cm
- Basic Specifications - EAN
- 0810084698747
- Basic Specifications - Form Factor
- Wall / ceiling mountable
- Basic Specifications - Frequency Band
- 2.4 GHz, 5 GHz
- Basic Specifications - Included Accessories
- Wall/ceiling mounting kit
- Basic Specifications - Manufacturer's Part Number
- U7-LITE
- Basic Specifications - Model
- Ubiquiti UniFi U7 Lite
- Basic Specifications - OS Required
- UniFi OS, UniFi Network 9.0.114 or later
- Basic Specifications - Performance
- Maximum data rate (2.4 GHz): 688 Mbps ¦ Maximum data rate (5 GHz): 4.3 Gbps
- Basic Specifications - Power
- DC 42.5 - 57 V
- Basic Specifications - Power Over Ethernet (PoE) Supported
- PoE
- Basic Specifications - Product Description
- Ubiquiti UniFi U7 Lite - radio access point - Wi-Fi 7
- Basic Specifications - Weight
- 313 g
- Environmental Parameters - Humidity Range Operating
- 5 - 95% (non-condensing)
- Environmental Parameters - Max Operating Temperature
- 40 °C
- Environmental Parameters - Min Operating Temperature
- -30 °C
- Expansion / Connectivity - Interfaces
- 1 x 2.5GBase-T (PoE) - RJ-45
- General - Depth
- 3.3 cm
- General - Device Type
- Radio access point
- General - Height
- 17.15 cm
- General - Weight
- 313 g
- General - Width
- 17.15 cm
- Miscellaneous - Compliant Standards
- UKCA, WEEE, EAC, FCC, IC
- Miscellaneous - Included Accessories
- Wall/ceiling mounting kit
- Networking - Authentication Method
- RADSEC, RADIUS
- Networking - Capacity
- Spatial streams: 4 ¦ Connected devices: 200+
- Networking - Compliant Standards
- IEEE 802.11v, IEEE 802.11r, IEEE 802.11k
- Networking - Connectivity Technology
- Wireless
- Networking - Data Link Protocol
- IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6), IEEE 802.11be (Wi-Fi 7)
- Networking - Data Transfer Rate
- 4.3 Gbps
- Networking - Encryption Algorithm
- TLS
- Networking - Features
- 2x2 MU-MIMO technology, Wireless Mesh support, band steering, Fast Roaming, BSS transition management, radio resource management (RRM), advanced radio management, Passpoint Release 2, Captive Portal, custom branding landing page support, voucher authentication, payment-based authentication, external portal server support, password authentication, Guest Isolation, Private Pre-Shared Key (PPSK), client isolation, rate limit, WiFi schedules, UV stabilised polycarbonate enclosure, LED status indicator, locking notch, reset button
- Networking - Form Factor
- Wall / ceiling mountable
- Networking - Frequency Band
- 2.4 GHz, 5 GHz
- Networking - Max Coverage Area
- Up to 115 sq.m
- Networking - Performance
- Maximum data rate (2.4 GHz): 688 Mbps ¦ Maximum data rate (5 GHz): 4.3 Gbps
- Power - Power Over Ethernet (PoE) Supported
- PoE
- Software / System Requirements - OS Required
- UniFi OS, UniFi Network 9.0.114 or later
